WJPS-450 / 680
Shaftless Offset Intermittent / Full Rotary Label Press
Wanjie's answer to the short-run/long-run problem. Runs intermittent for small orders and switches to full rotary at up to 200 m/min for volume — one machine, both economics.
Highlights
- Intermittent and full rotary modes in a single machine
- Up to 200 m/min in full rotary
- 11 servo motors, gearless drive
- Chilling drum on every printing unit — perfect on film
- PS plate: short, simple, low-cost platemaking
Choose your size
One platform, built in several web widths. Pick a size for its full data plate, or set the sizes side by side the way the brochure prints them.
Showing WJPS-450
- Max web width
- 460 mm
- Max printing width
- 450 mm
- Max unwinding diameter
- 1000 mm
- Max rewinding diameter
- 1000 mm
- Material — intermittent
- Paper 40–350 g/m² · Film 0.03–0.3 mm
- Material — full rotary
- Paper 40–350 g/m² · Film 0.012–0.3 mm
- Printing length — full rotary
- 435–689 mm
- Printing length — intermittent
- 180–450 mm
- Printing speed — intermittent
- 30–180 rpm/min
- Printing speed — full rotary
- 30–200 m/min
- Power
- Depends on configuration
- UV
- Depends on configuration
- Overall dimensions
- Depends on configuration
- Machine weight
- Depends on configuration
Printing speed is subject to the length and quality of the printing material.
The right machine for converters whose order book is splitting between 5,000-label pharma jobs and 200,000-label FMCG runs.
Wanjie India
What makes it run
Plate making is short, simple, low cost — and the printed result is exquisite and delicate. Suits a wide range of materials.
Close-ups of the WJPS-450/680: printing units, chilling drums and control stations
Configure it for your floor
Options
- Flexo unit
- Screen printing unit
- Gravure unit
- Hot stamping
- Cold stamping
- Variable data / inkjet
What it runs
Applications
- High-volume FMCG
- Film and BOPP labels
- Shrink sleeve base printing
- Multi-SKU cosmetic ranges
Machines that work alongside it
Want to see the WJPS-450 / 680 running?
Our Sanand experience centre runs live Wanjie machines. Bring your substrate and your artwork, and watch your own job come off the roll.
