WJPS-660 / 700
Shaftless Offset Intermittent Rotary Label Press
Wide-web intermittent offset for cartons, in-mould labels and large-format wet-glue work — up to seven colours at 400 g/m².
Highlights
- Up to 7 colours, 690 × 560 mm printing area
- Handles up to 400 g/m² board
- CCD registration on the fly
- BST web guide and pneumatic paper loading
Choose your size
One platform, built in several web widths. Pick a size for its full data plate, or set the sizes side by side the way the brochure prints them.
Showing WJPS-660
- Max web width
- 660 mm
- Max printing area (W×L)
- 650 × 420 mm
- Max unwinding diameter
- 1000 mm
- Max rewinding diameter
- 1000 mm
- Material thickness
- 80–400 g/m²
- Printing length
- 210–420 mm
- Printing speed
- 30–160 rpm/min
- Power
- 49.35 kW / 7 colours (3ph 380 V)
- UV
- 12 kW / colour (380 V)
- Overall dimensions
- 13000 × 4000 × 1900 mm / 7 colours
- Machine weight
- 20000 kg / 7 colours
Printing speed is subject to the length and quality of the printing material.
Wide-web offset of this class is rare in India — most converters outsource this work today.
Wanjie India
What makes it run
Imported electric components with CPU/DOS servo control — high response, accurate towing, safe running.
Close-ups of the WJPS wide-web press: web guide, ink fountain and touch screen
Configure it for your floor
Options
- Flexo varnishing unit
- Cold stamping unit
- Rotary die-cutting unit
- Automatic ink controller
Accessories
- BST web guide
- Pneumatic paper loading
- Flexo varnishing unit
- Touch screen per unit
- CCD
- Partition ink fountain
- Heavy offset printing unit
What it runs
Applications
- Folding cartons
- In-mould labels
- Wet glue labels
- Large format cosmetics
Machines that work alongside it
Want to see the WJPS-660 / 700 running?
Our Sanand experience centre runs live Wanjie machines. Bring your substrate and your artwork, and watch your own job come off the roll.
